Since 1977 the name IMA has been synonymous with quality and technological innovation. For 45 years our company has dedicated itself to the production of automated machinery and equipment (specialized in handling and management systems of cloth rolls, spreading solutions, labelling and automatic cutting machines and software programs for the complete organization of the cutting room) for the garment industry and not only. After being pioneers of digital technology with the creation of the first fulldigital spreading machine we are now pioneers of Industry 4.0 with our latest creation: “Syncro Cutting Room”. Specialized in handling and management systems of cloth rolls, spreading solutions, automatic cutting machines and software programs for the Complete organization of the cutting room.
Tempest Plus 921.30 – High precision for small series productions
Tempest Plus 30 – Automatic cutting machine for lays up to 30 mm compressed according to the type of fabric to cut. Structurally designed to achieve the highest level of performance and to reduce downtime during processing with high dynamic performances. The software of the machine is installed on a PC on board, increasing its efficiency and productivity, thanks to intuitive and flexible applications. Available as standard the possibility of storing an unlimited number of cutting profiles to be load if necessary.ntegrable for Industry 4.0 and IMA Syncro Cutting Room System. The innovative management of the vacuum system guarantees a reduction in consumption with the same performance. The digital technology totally based on the ETHERCAT communication protocol allows Checking the status of the machinery in real time, with self-diagnosis functions and automatic options for adjusting the performance based on the type of work in progress.
Among the most important innovations we find gantry management of the bridge movement, management of differentiated pressure of the utilities most involved in the cutting process, touch screen placed on the bridge to allow the operator greater ease of intervention, Equipped with an inverter on all the utilities, an eco-friendly management of each motorization is ensured.
Technical features:
• Cutting window length: 175 cm
• Cutting height: from single lay up to 30 mm of compressed fabric
• Installed power: 22 kw
• Power consumption: 6 kw
• Temperature from 10 ° to 60 °
• Umidity from 30% to 80% without condensation
• Voltage 400 V 3 PH 50/60 Hz
• Weight: ~ 2500 /2700 kg
890 Spreading and Unrolling Machine
Automatic spreading and unrolling machine IMA “Phoenix” series. Fabric Feeding, Tension Free and Automatic Braking systems digitally controlled. Equipped with onboard touch-screen to control spreading operations. Auto-diagnosis function. Lowered cradle to facilitate fabric roll change. Programmable bi- directional cutting device.
Automatic edge alignment and automatic stop for roll change. Fully automatic spreader adapted to be interfaced with planning offices and CAD systems. Possibility to program on the touch screen spreading speed and acceleration. Automatic knife box lift. Standard spreading is face up and zig-zag without end cuts and without clamps. Face to face spreading is available as optional. Suitable for even/random step spreading. Possibility to stop the spreader and spreading as unrolling machine (single ply)
Technical Specifications
• Spreading speed: up to 100 m/min
• Lay Thickness: 20 cm
• Voltage: 400V / 3 / 50 Hz
• Capacity: 150Kg
• Roll Diameter: 50cm
